Covers for 2-Way Slip-In Cartridge Valves - Series C*B / C*H - C016BN12N
SKU:
C016BN12N
In Stock (15 items)
3 views
€0,00
VAT Included
Product Summary
Parker's cover with stroke limiter series C*B and C*H are universally applicable for compact manifold block installation and available in many different sizes.
Product Description
Parker's cover with stroke limiter series C*B and C*H are universally applicable for compact manifold block installation and available in many different sizes.
The cover with X-connection and stroke limiter series C*B and the cover with stroke limiter and DC mounting pattern series C*H for 2-way slip-in cartridge valves are universally applicable and ensure a reliable operation.
2-way slip-in cartridge valves are hydraulically controlled seat valves that are designed for compact block installation. Slip-in cartridge, cover and pilot system are components of Parker's modular DIN cartridge system which permits single and combined functions.
Markets:
• Industrial
• Molding
• Oil & Gas
Features/Benefits:
• Compact, proven design that represents our long-term experience in hydraulics - increases reliability
• Comprehensive range - allow maximum flexibility for single and combined functions
• 6 different sizes from NG16 to NG63 - suitable for almost every application
• Short delivery time - no warehousing necessary
Applications:
• Suitable for general hydraulic applications
• General presses
• Die cast
• Injection molding
2-way slip-in cartridge valves are hydraulically controlled seat valves that are designed for compact block installation. Slip-in cartridge, cover and pilot system are components of Parker's modular DIN cartridge system which permits single and combined functions.
Markets:
• Industrial
• Molding
• Oil & Gas
Features/Benefits:
• Compact, proven design that represents our long-term experience in hydraulics - increases reliability
• Comprehensive range - allow maximum flexibility for single and combined functions
• 6 different sizes from NG16 to NG63 - suitable for almost every application
• Short delivery time - no warehousing necessary
Applications:
• Suitable for general hydraulic applications
• General presses
• Die cast
• Injection molding
Note: C*H for 2-way slip-in cartridge valves is not longer available from Parker, please refer to the recommended products for a replacement.
The Parker C*B and C*H series impact limiting covers are designed as a critical component in industrial automation systems. These covers provide a universal solution for compact manifold block mounting and are available in various sizes for different applications. Made from NBR material, these covers perform effectively within a temperature range of -20 °C to +80 °C. Particularly, they prevent impact in hydraulic and pneumatic systems, extending system lifespan and preventing failures. Manufactured in compliance with Parker's high engineering standards, this product stands out for its reliability and durability. It is widely used in industrial sectors such as automotive, machinery, and manufacturing. The Parker brand offers one of the best solutions in the market through technical expertise and quality material usage.
Technical Specifications
| Cover | With X-connection and stroke limiter |
| Weight | 0.9 kg |
| Function | 2-Way |
| Flow Rate | n/a |
| Body Material | Cast Iron |
| Configuration | Cover with Mounting Pattern for Pilot Valve Assembly |
| Mounting Type | Slip-in Cartridge |
| Seal Material | NBR |
| Actuation Type | Hydraulic Pressure |
| For Fluid Type | Hydraulic Oil According to DIN 51524 |
| Operation Type | n/a |
| Orifice 1 Size | 1.2 mm |
| Orifice 2 Size | na |
| Orifice 3 Size | na |
| Orifice 4 Size | na |
| Product Series | Seat Valve |
| Adjustment Type | Screw/spindle |
| Port Connection | NG16 |
| Maximum Flow Rate | n/a |
| Maximum Operating Pressure | 350 bar (depending on pilot valve) |
| Maximum Operating Temperature | 60 °C |
| Minimum Operating Temperature | -20 °C |
| Brand | Parker |
| Model | Covers for 2-Way Slip-In Cartridge Valves - Series C*B / C*H - C016BN12N |
| SKU | C016BN12N |
| Main Category | Parker |
