DM1-0-1-CLIN-Z-H-LE
DM1-0-1-CLIN-Z-H-LE
DM1-0-1-CLIN-Z-H-LE
DM1-0-1-CLIN-Z-H-LE
DM1-0-1-CLIN-Z-H-LE
Fortress Safety Fortress Safety

DM1-0-1-CLIN-Z-H-LE

In Stock (100 items)
62 views
€0,00

VAT Included

Product Summary

Door modules are used to control access to safeguarded areas. Door modules will retain/trap an actuator until the correct key is inserted and rotated. When using multiple locks, additional sequential...
(100 items available)

Product Description

Door modules are used to control access to safeguarded areas. Door modules will retain/trap an actuator until the correct key is inserted and rotated. When using multiple locks, additional sequential processes can be administered.
The Fortress Safety DM1-0-1-CLIN-Z-H-LE door module is designed to meet high standards in industrial security. This module provides an excellent solution for controlling access to safeguarded areas. Users can benefit from the ability to retain or trap an actuator until the correct key is inserted and rotated. When utilizing multiple locks, additional sequential processes can also be administered. With a temperature range capable of withstanding up to 80°C, this door module offers long-lasting performance thanks to its high-quality die-cast zinc body and pearl bronze plated finish. It is CE marked, confirming compliance with all applicable directives, ensuring that the highest security standards are met. The reliability of the Fortress Safety brand combined with the technical superiority of the DM1-0-1-CLIN-Z-H-LE model makes it an ideal solution for industrial facilities. Enhance your security and optimize access control with this exceptional product.

Technical Specifications

Category Cat. 4, PLe (EN / ISO 13849-1) and SIL3 (EN/IEC 62061)
Features Mechanical Only
Internals Full stainless steel
Standards ISO EN14119:2013 EN13849-1:2008 EN13849-2:2012 EN62061:2005
Part Number DM1-0-1-CLIN-Z-H-LE
Temperature Mechanical Components to 80°C gard
Certifications CE marked for all applicable directives
Lock Mechanism Die-cast zinc body with stainless operating mechanism (selected separately)
Retention Force 2500N
Housing Materials Die-cast zinc body with pearl bronze plated finish
Functional Safety Data - B10d 5,000,000
Brand Fortress Safety
Model DM1-0-1-CLIN-Z-H-LE
Main Category Fortress Safety
