Product Summary

An interlock without locking, featuring an AT tongue, an AT head, and a forced extracted key adaptor with a master lock and dust cover.
(100 items available)

Product Description

An interlock without locking, featuring an AT tongue, an AT head, and a forced extracted key adaptor with a master lock and dust cover.
The TA2T6EKL7ST401 model from Fortress Safety is an interlock system that offers high performance and durability in the industrial safety sector. Made from stainless steel, this product ensures reliability even in harsh working conditions. With a voltage capacity of 2500V AC, it can be used across a wide range of applications. The PLe performance level and IP67 protection class ensure that this interlock is resistant to dust and water, elevating safety standards to the highest level. The TA2T6EKL7ST401 model features a user-friendly design with an AT head and AT tongue. The key adaptor, integrated with a forced extraction mechanism, provides additional security. It is an ideal solution for ensuring the safe operation of industrial machinery. With its compliance with safety standards and robust construction, this product stands out in the industry. It is a solid choice for industrial automation and safety systems, making it an essential component for maintaining a secure working env...

Technical Specifications

DC Position Monitoring
λd 10%
B10d 5000000
Materials Stainless Steel to BS3146
Cable Size 28 – 24 AWG
Environment Indoor, Outdoor
Part Number TA2-T6-EKL7-ST401
Connector Type Spring Activated Vibration Proof Block
Paint Finishes Gloss Powder Coat on Passivated Base Material
Control Voltage 24V ac/dc, 110V ac, 230V ac
Mechanical Life 1,000,000 Switching Cycles
Operating Force 5N
Retention Force 10,000N(locked)
Housing Materials Zinc Alloy to BSEN12844
Performance Level PLe
Ingress Protection IP67
Insulating Voltage 2500V AC
Internal Materials All Stainless Steel
Diagnostic Coverage A maximum DC of 99% can be achieved with suitable monitoring
Utilisation Category AC 15 or DC 13
Insulating Resistance 20M Ohm
Maximum Switch Current 3A
Minimum Switch Current 1mA at 5VDC
Brand Fortress Safety
Model TA2T6EKL7ST401
Main Category Fortress Safety
