Product Summary
A long-body solenoid-controlled interlock with Power-to-Unlock, auxiliary release, and monitored safety circuits. Includes control options and an escape release with automatic reset.
Product Description
A long-body solenoid-controlled interlock with Power-to-Unlock, auxiliary release, and monitored safety circuits. Includes control options and an escape release with automatic reset.
The Fortress Safety EI2A6LR411L0BUWYNT04706F2D1 model is a high-performance long-body solenoid-controlled interlock designed for industrial safety applications. Equipped with a powerful "Power-to-Unlock" mechanism, this product offers auxiliary release options for quick access in emergencies. Monitored safety circuits enhance the system's reliability and performance, making it a trusted choice for various settings. With an IP65 protection rating, it is resistant to dust and water, ensuring safe operation even in harsh industrial environments. This model boasts a PLe performance level and is constructed from stainless steel in compliance with BS3146 standards. Fortress Safety's EI2A6LR411L0BUWYNT04706F2D1 is the ideal solution for factories, automation systems, and other industrial applications. Choose this product to enhance safety measures and ensure operational efficiency.
Technical Specifications
| B10d | 5000000 |
| Features | Escape Release, Power-to-Unlock |
| Lamp Life | 100,000 hrs on time |
| Cable Size | 26 – 14 AWG |
| Environment | Indoor, Outdoor |
| Part Number | EI2-A6-LR411-L0BUWYN-T04706F2D1 |
| Connector Type | Spring Activated Vibration Proof Block |
| Paint Finishes | Gloss Powder Coat on Passivated bodies |
| Control Voltage | 24V DC |
| Mechanical Life | 1,000,000 Operating Cycles |
| Operating Force | 5NM |
| Retention Force | 10,000N(locked) |
| Actuator Contact | 2NC 1NO |
| Solenoid Voltage | 24V DC |
| Housing Materials | Zinc Alloy to BSEN12844 |
| Performance Level | PLe |
| Solenoid Contacts | 2NC 1NO |
| Ingress Protection | IP65 |
| Internal Materials | Stainless Steel to BS3146 |
| Diagnostic Coverage | A maximum DC of 99% can be achieved with suitable monitoring |
| Switches Conformance | DIN VDE 0060 Part 206 & IEC 947-5-1 |
| Maximum Switch Current | 0.1A |
| Minimum Switch Current | 1mA at 5VDC |
| EStop Switching Principal | Positive Break |
| Switching Contact Element | Pushbutton – 1NO Emergency Stop – 2NC |
| Solenoid Voltage Tolerance | 90% to 110% of nominal (Main Body) |
| Brand | Fortress Safety |
| Model | EI2A6LR411L0BUWYNT04706F2D1 |
| Main Category | Fortress Safety |
