Fortress Safety
Fortress Safety
NO2S6R8EKR1SRP11NDP3P6P2EINPF07
In Stock (100 items)
193 views
€0,00
VAT Included
Product Summary
A solenoid-controlled interlock with Power-to-Unlock, auxiliary release, and monitored safety circuits. Features a slimline head, push escape release, forced extracted key adaptor, and proNet for netw...
Product Description
A solenoid-controlled interlock with Power-to-Unlock, auxiliary release, and monitored safety circuits. Features a slimline head, push escape release, forced extracted key adaptor, and proNet for network connectivity (available for PROFINET / PROFIsafe, EtherNet/IP / CIP Safety, and EtherCAT / FSoE).
The Fortress Safety NO2S6R8EKR1SRP11NDP3P6P2EINPF07 model is a revolutionary solenoid-controlled interlock system designed for industrial safety. This product features Power-to-Unlock functionality, auxiliary release, and monitored safety circuits, ensuring optimal safety in various applications. Its slimline design makes it suitable for installation in confined spaces, while the user-friendly push escape release mechanism provides rapid response in emergency situations. The forced extracted key adaptor further enhances security. With ProNet connectivity, it is compatible with PROFINET / PROFIsafe, EtherNet/IP / CIP Safety, and EtherCAT / FSoE networks.
Operating within a voltage range of 90% to 110% of nominal, the NO2S6R8EKR1SRP11NDP3P6P2EINPF07 is constructed entirely from stainless steel. It boasts a performance level of Cat 4 / PLe and an IP65 protection class, making it resistant to external factors. With these features, it provides maximum safety and performance in industria...
Technical Specifications
| DC | Position Monitoring |
| λd | 10% |
| B10d | 5000000 |
| MTTFd | MTTFd > 100y PFH=2.44 E-9 |
| DC avg | High |
| Features | Escape Release, Power-to-Unlock, Network Communication |
| Cable Size | 28 – 24 AWG |
| Environment | Indoor, Outdoor |
| Part Number | NO2-S6-R8-EKR1-SRP11-NDP3P6P2EIN-PF07 |
| Paint Finishes | Gloss Powder Coat on Passivated bodies |
| Supply Current | ?750mA |
| Supply Voltage | 24V DC +/- 10% |
| Control Voltage | 24V ac/dc, 110V ac, 230V ac |
| Mechanical Life | 1,000,000 Switching Cycles |
| Retention Force | 10,000N(locked) |
| Actuator Contact | 2NC 1NO |
| Solenoid Voltage | 24V ac/dc, 110V ac, 230V ac |
| Housing Materials | Die-cast Zinc Alloy |
| Performance Level | PLe |
| Solenoid Contacts | 2NC 1NO |
| Ingress Protection | IP65 |
| Internal Materials | All Stainless Steel |
| Diagnostic Coverage | A maximum DC of 99% can be achieved with suitable monitoring |
| Switches Conformance | DIN VDE 0060 Part 206 & IEC 947-5-1 |
| Maximum Switch Current | 3A |
| Minimum Switch Current | 1mA at 5VDC |
| Maxiumum Switching Voltage | 230V AC Max |
| Solenoid Voltage Tolerance | 90% to 110% of nominal |
| CateGory / Performance Level | Cat 4 / PLe |
| Solenoid Rating (Duty Cycle) | 100% |
| Brand | Fortress Safety |
| Model | NO2S6R8EKR1SRP11NDP3P6P2EINPF07 |
| Main Category | Fortress Safety |
