Product Summary
A solenoid-controlled interlock with Power-to-Lock, unmonitored solenoid safety circuits, and no manual release. Features a proHandle, an AT head, and an extracted key adaptor with a standard lock and...
Product Description
A solenoid-controlled interlock with Power-to-Lock, unmonitored solenoid safety circuits, and no manual release. Features a proHandle, an AT head, and an extracted key adaptor with a standard lock and padlockable dustcover.
The EN2T6EKL3SL461 model from Fortress Safety is a high-performance solenoid-controlled interlock system designed for industrial safety applications. Equipped with a Power-to-Lock feature, it offers unmonitored solenoid safety circuits and eliminates the need for manual release, ensuring maximum security in your operations.
This model operates within a voltage range of 90% to 110% of the nominal value and is constructed entirely from stainless steel, making it durable and reliable. Meeting the advanced performance level of PLe standards, it complies fully with safety regulations. With an IP67 protection class, the EN2T6EKL3SL461 provides dependable performance even in challenging industrial environments. User-friendly features, such as the proHandle, AT head, and a standard lock with a padlockable dust cover, make this model easy to use while significantly enhancing your workplace safety. Elevate your security measures with Fortress Safety's EN2T6EKL3SL461.
Technical Specifications
| DC | Position Monitoring |
| λd | 10% |
| B10d | 5000000 |
| Features | Power-to-Unlock |
| Cable Size | 28 – 24 AWG |
| Environment | Indoor, Outdoor |
| Part Number | EN2-T6-EKL3-SL461 |
| Paint Finishes | Gloss Powder Coat on Passivated Base Material |
| Control Voltage | 24V ac/dc, 110V ac, 230V ac |
| Mechanical Life | 1,000,000 Switching Cycles |
| Retention Force | 10,000N(locked) |
| Actuator Contact | 2NC 1NO |
| Solenoid Voltage | 24V ac/dc, 110V ac, 230V ac |
| Housing Materials | Zinc Alloy to BSEN12844 |
| Performance Level | PLe |
| Solenoid Contacts | 1NO |
| Ingress Protection | IP67 |
| Internal Materials | All Stainless Steel |
| Diagnostic Coverage | A maximum DC of 99% can be achieved with suitable monitoring |
| Switches Conformance | DIN VDE 0060 Part 206 & IEC 947-5-1 |
| Maximum Switch Current | 3A |
| Minimum Switch Current | 1mA at 5VDC |
| Solenoid Voltage Tolerance | 90% to 110% of nominal |
| Solenoid Rating (Duty Cycle) | 100% |
| Brand | Fortress Safety |
| Model | EN2T6EKL3SL461 |
| Main Category | Fortress Safety |
